Koden Radar MDC-7912P

Koden MDC-7912P 12 KW with 30 m cable

Spesification
◆Display unit : MRM-108P
◆Operation Unit : MRO-108P
◆Display Size : –
◆Display resolution : 1280×1024 pixels
◆effective diameter : –
◆Off-centering : Max 75%
◆Echo area : 1 types (inside of effective diameter)
◆Presentation modes : Head-up, North-up (True motion)***, North-up (Relative motion)*, Course-up
(True motion)***, Course-up (Relative motion)*
◆Indication Type : PPI
◆Video Level : 16
◆Range unit : NM, sm, km, kf, ky
◆Alarms : Echo (IN / OUT), TT / AIS (CPA / TCPA), Guard zone etc.
◆Function :CFAR (Clutter rejection), Interference rejection, Expansion, Process (Residual image, ◆Averaging), VRM, EBL, Parallel index, ERBL, Cursor position, Trail (true / relative)***, Own ship past track***, MAP*** (Event mark etc.), Analog RGB output, Trial Manoeuvre***,VDR output, Inter-switch, C-map chart***( MDC-7000 / 7900), Non official chart display (C-map chart)(MDC-7000P / 7900P)
◆Input data format dan sentences : NMEA0183 (4800 / 9600 / 19200 / 38400 bps)
BWC, DBT, DPT, DTM, GBS, GGA, GLC, GLL, GNS, HDG, HDM, HDT, MTW, MWD, RMA, RMB, RMC, ROT, RTE, THS, VBW, VDM, VDO, VDR, VHW, VTG, WPL, XTE, ZDA
◆Output data format and sentences : NMEA0183 (4800 / 9600 / 19200 / 38400 bps) OSD, RSD, TLB, TLL, TTD, TTM
◆NMEA ports : Total 3 : input and Output 3
◆AIS interface : 1000 targets
◆TT : 100 targets
◆Power Suply : 21.6 to 41.6 VDC
